Note: Some 2.50 mm parts are incorrectly sold on the internet as 2.54 mm (0.100 in), and the 1.25 mm parts as 1.27 mm (0.050 in). website has a tool which allows users to check certain models for their authenticity and specifications. To minimize confusion, it is best to describe a connector using: the manufacturer's name, exact connector series, and optionally the pitch, such as "JST-XH" or "JST-XH-2.50mm" or "2.50mm JST XH-series" or other variations.

It is very common in blogs and websites to incorrectly name a specific connector only by the name of the manufacturer. Connector confusion on the internet Įnd-users and 3rd-party sellers on eBay often describe connectors by their wrong name thus perpetuating confusion of the exact series of a specific connector. Some JST surface-mount headers are designed to handle higher temperatures of reflow soldering. Used in some RGB LED decorative light strips.Ī majority of JST through-hole headers can't withstand the temperatures required for reflow soldering, because the plastic has a lower melting point since they were designed for wave soldering methods. The PCB (wire-to-board) connectors are available in top (vertical) or side (horizontal) entry, and through-hole or surface-mount. JST manufactures a large number of series (families) of connectors.

The term "JST" is sometimes incorrectly used as a vernacular term meaning any small white electrical connector mounted on PCBs. JST connectors are used in many types of products, and commonly used by electronics hobbyists and consumer products for rechargeable battery packs, battery balancers, battery eliminator circuits, 3D printers, and radio controlled servos. JST manufactures numerous series (families) and pitches (pin-to-pin distance) of connectors. JST connectors are electrical connectors manufactured to the design standards originally developed by J.S.T.
